MERIDA Reacto 4000 Disc (2027) (Pre-Order Now)

FRAME
REACTO CF3 V
material: carbon
700x32C max. wheelsize
100x12/ 142x12mm axle standard
BB86,5 bottom bracket standard

FORK
MERIDA REACTO CF3 V DISC
material: carbon
700x32C max. wheelsize

BRAKES
Shimano 105
2 piston
hydraulic

ROTORS
Shimano RT54
160mm

BRAKE LEVER
Shimano 105

HEADSET
MERIDA TEAM SL
(RCT 608 neck)

HANDLEBAR
MERIDA EXPERT CW
material: aluminium
380mm (3S-XXS-XS-S)
400mm (M-L) 420mm (XL)

HANDLEBAR STEM
MERIDA EXPERT SL 2PII
material: aluminium
-9° stem angle
90mm (3S/XXS/XS), 100mm (S), 110mm (M/L), 120mm (XL)

GRIP
MERIDA ROAD EXPERT

DERAILLEUR (F)
Shimano 105

DERAILLEUR (R)
Shimano 105
GS
mechanical *12 speed

SHIFTERS
Shimano 105 disc

SEAT POST
MERIDA REACTO V S-FLEX
Aero Shape
0mm setback
material: Carbon

SEAT CLAMP
MERIDA REACTO V

SADDLE
Prologo Akero RS PAS T2.0
incl. MERIDA minitool

CHAIN
Shimano M6100-12

CRANK
Shimano 105 R7100
52-36 teeth
160 mm-3S, 165 mm-XXS/XS, 170 mm-S/M, 172.5 mm-L/XL

FREEWHEEL
Shimano 105 R7101
11-34 teeth
12 speed

BOTTOM BRACKET
Shimano SM-BB71-41B
Pressfit 86.5

HUBS
Shimano HB-TC500 / Shimano HB-TC500-HL
100x12mm width front hub
28 spoke holes
Centerlock
12x142mm width rear hub
28 spoke holes
Centerlock

RIM
MERIDA EXPERT CW
19mm inner width
30mm height
material: aluminium
Tubeless ready (tubeless tape and valves not included)

TYRE FRONT
Continental Grand Prix
700x28C
fold *

TYRE REAR
Continental Grand Prix
700x28C
fold *

AXLES
MERIDA EXPERT SL
including removable lever
6/4mm allen key

SPOKES
Double Butted Black stainless
